Salient Feature:
- Quality tablet production at high speed.
- Design conforming to GMP norms.
- Exquisitely engineered body kept in a cabinet.
- Simple and convenient operation, offering operator protection, cleanliness and ease of maintenance.
- All the tablet parameters can be fine tuned during the Operation of the machine from outside the Tableting zone.
- PLC controls.
- Also Available 55 & 61 Stn. model
Technical Specification
| Number of stations | 37 | 45 |
| Type of tooling | D | B |
| Output (tablets/hour) | 80000 to 265000 | 96000 to 324000 |
| Turret RPM | 18 to 50 | 18 to 50 |
| Max. operating pressure | 10 Tons | 6.5 Tons |
| Max. tablet diameter | 23 mm | 7/16" (15.9mm) |
| Depth of fill | 20 mm | 11/16"(17.5 mm) |
| Upper punch penetration | 1/8" to 5/16" (3.2 to 8 mm) | 1/8" to 5/16" (3.2 to 8 mm) |
| Power (total) | 7 kW / 9.5 hp | 7 kW / 9.5 hp |
| Main electric motor | 5.5 kW / 7.5 HP, 1440 RPM, 3 Ph | 5.5 kW / 7.5 HP, 1440 RPM, 3 Ph |
| Powder feeder motor | 0.19 kW / 0.25 HP, 1440 RPM, 3 Ph | 0.19 kW / 0.25 HP, 1440 RPM, 3 Ph |
| Overall dimensions (mm) | 1470 x 1400 x 1870 H Approx. | 1470 x 1400 x 1870 H Approx. |
| Net weight | 2500 kg | 2500 kg |
| Case dimensions (mm) | 1680 x 1830 x 2240 H | 1680 x 1830 x 2240 H |
