SINGLE ROTARY TABLET PRESS

  1. Home
  2. Products
  3. SINGLE ROTARY TABLET PRESS
...

Salient Feature:

  • Rigid and Robust standard design machine.
  • Variable Speed through Variable Speed Pulley.
  • Maximum Output 50,000 Tablet / hr.
  • Maximum Operating Pressure 10 Tons.
  • Easy to operate, clean and maintenance.
  • Supplied with Round Base Body.

Optional Features:

  • PLC with HMI Controls.
  • Also Available outside controls.

Technical Specification

MODELSMD3SMD3SMD3
Station162023
Tooling‘D’‘D’‘D / B’
Output Tab. / Hour35,00035,00058,000
Max. Dia23 mm23 mm16 mm
Max. Depth of fill20 mm 20 mm 20 mm
Max. operating Pressure10 tons10 tons10 tons
Electrical Power2 HP. /3 ph., 960  RPM, 60 Hz2 HP. /3 ph., 960  RPM, 60 Hz2 hp. /3 ph., 960  RPM, 60 Hz
Overall Dimensions (mm)980 x 1120 x 1820 (H) Approx.980 x 1120 x 1820 (H) Approx.980 x 1120 x 1820 (H) Approx.
Net Weight1000 Kgs. Approx.1000 Kgs. Approx.1000 Kgs. Approx.
Gross Weight1200 Kgs. Approx.1200 Kgs. Approx.1200 Kgs. Approx.
