SALIENT FEATURES
- Direction for beaters can be changed by reversible switch.
- All Contact parts can be easily and quickly dismantled and cleaned.
- Cylindrical screen for higher output.
- Castor Wheels provided for mobility.
- Beaters & Scrapper blades of S.S.316 Quality.
- Flame Proof electrical components can be provided at extra Cost.
Technical Specification
| Model | SMMM |
| Height | 930 mm |
| Width | 685 mm |
| Length | 435 mm |
| Charging Height | 790 mm |
| Discharge Height | 350 mm |
| Screen Size | Dia 168 X 90 mm |
| Contact Part | S.S. 316 |
| Non-Contact Part | S.S. 304 |
| Electricals | 0.5 HP, 3 Ø , 1440 RPM / A.C. |
| Net Weight | 70 Kg. Approx. |
| Rotor Speed | 750/1500/2300/3000 RPM. |
| Beaters | 12 No. with Knife & Impact Edge / 2 No. Scraper Blades |
| Starter | Reverse & Forward Switch |
